Messaging | Message Builder
Reference Manual 141
Encoder Value: Indicates the encoder/tachometer pulse value from trigger to
the code being read
Laser Number: If more than one laser is present in the working device, this
item indicates the laser used to read the code
Reading Persistence: Indicates how many times the laser beam has crossed
the complete code during the reading phase
Package Related Items
Select a package related item from those available in the drop-down list. This
option is available when Item Type > Package Related Item has been selected.
Package Sequence Number: Indicates the sequential number assigned to the
package.
Total Read Bitmap: Indicates the complete reading mask related to all codes
read during the reading phase
Failure Bitmap: 32-bit mask indicating which devices in the network are in
fault (when character <1> is present in the related position)
Total Read Count: Indicates the sum of all Code-related Total Reading Counts
of each code read during the reading phase
Read Count (by device): Indicates the number of codes read during the
reading phase by the device
Minimum Code Distance: Indicates the distance of the code closest to the
device read during the reading phase
Maximum Code Distance: Indicates the distance of the code most distant
from the scanner that has been read during the reading phase
Decode Mode (Master): Indicates the programmed Reading Mode, either
Linear or Reconstruction
Number of Rejected Codes: Indicates the number of codes rejected during
the internal analysis (unexpected code, multiple read, discarded by the
programmed logical rule)
Package Length: Indicates the approximate length of the package
Start Trigger Encoder Value: Indicates the encoder/tachometer pulse value
when the package first hits the trigger PS
End Trigger Encoder Value: Indicates the encoder/tachometer pulse value
when the package exits the trigger PS
Transmit Encoder Value: Indicates the encoder/tachometer pulse value when
the data transmit occurs
Current Trigger Count: Indicates the number of trigger cycles that have
occurred
Working Hours (By Device): Indicates the total number of hours the device has
been active
Total Good Reads: Indicates the total number of barcodes successfully read
Total No Reads: Indicates the total number of barcodes that were not read
Total Multi Reads: Indicates the number of times packages carried more
codes than the scanner is programed to read
Total Partial Reads: Indicates the total number of barcodes only partially read
Protocol Index/Aux Message: Indicates the programmed protocol index
string data
Parcel Length: This is a field received in the Protocol Index from a
dimensioner.
Parcel Width: This is a field received in the Protocol Index from a
dimensioner.
Parcel Height: This is a field received in the Protocol Index from a
dimensioner.
Parcel Volume: This is a field received in the Protocol Index from a
dimensioner.
Parcel Orientation Angle: This is a field received in the Protocol Index from a
dimensioner.
Isolated Parcel: This is a field received in the Protocol Index from a
dimensioner.
Cuboidal Parcel: This is a field received in the Protocol Index from a
dimensioner.
Dimensioner Ready: This is a field received in the Protocol Index from a
dimensioner.
Dimensioner Legal For Trade: This is a field received in the Protocol Index
from a dimensioner.
Parcel Box Length: This
is a field received in the Protocol Index from a
dimensioner.
Parcel Box Width: This is a field received in the Protocol Index from a
dimensioner.
Parcel Box Height: This is a field received in the Protocol Index from a
dimensioner.
