Datalogic DX8210 User Manual

User Interface
118 DX8210 Barcode Scanner
Profibus Settings, Profibus SC5000 Redundant
(SC5000 Profibus models)
Node Address
Enter a Node Value in the field provided, to define the value that distinguishes this
node from all other nodes on the same link. Each node identifies a device within the
network.
Valid values are in the range 0 - 126.
Node Address 126 forces the SSA (Set Station Address) service which allows the
Fieldbus Master to assign the slave node address.
Node Address (Working/ Protecting) SC500 Redundant
Enter a Node Value in the fields provided, to define the value that distinguishes
these nodes from all other nodes on the same link. Each node identifies a device
within the network. The behavior is controlled by the IP Selector parameter
in Modify Settings | Global Settings | Redundant Operation.
Valid values are in the range 0 - 126.
Node Address 126 forces the SSA (Set Station Address) service which allows the
Fieldbus Master to assign the slave node address.
Master Input Area Size
Enter a value from 8 - 144 bytes to define the size of the message command sent
from the Fieldbus module to the Fieldbus Master (Host). The default value is 8
bytes.
The maximum Input + Output Area Size for the Profibus interface is 152 bytes.
Master Output Area Size
Enter a value from 8 – 144 bytes to define the size of the message command sent
to the Fieldbus module from the Fieldbus Master (Host). The default value is 8
bytes.
The maximum Input + Output Area Size for the Profibus interface is 152 bytes.
Profinet Settings, Profinet SC5000 Redundant (SC5000
Profinet models)
Master Input Area Size
Enter a value from 8 - 56 bytes to define the size of the message command sent
from the Fieldbus module to the Fieldbus Master (Host). The default value is 8
bytes.
The maximum Input + Output Area Size for the Profinet interface is 64 bytes.
Master Output Area Size
Enter a value from 8 – 56 bytes to define the size of the message command sent to
the Fieldbus module from the Fieldbus Master (Host). The default value is 8 bytes.
The maximum Input + Output Area Size for the Profinet interface is 64 bytes.
Station Name (max. 32 chars)
This string identifies the node on the network as an alternative to the IP address. If
this value is changed by the host application during runtime, a reset is required in
order for changes to have effect.
The name can be made up only of letters or numbers. The . (dot) and - (dash)
characters can be used but not as the first or last character in the name.

The default name is Datalogic.
Station Name (Working / Protecting SC5000 Redundant
This identifies the node on the network as an alternative to the IP address. If this
value is changed by the host application during runtime, a reset is required in order
for changes to have effect. The behavior is controlled by the IP Selector parameter
in Modify Settings | Global Settings | Redundant Operation
.
The name can be made up only of letters or numbers. The . (dot) and - (dash)
characters can be used but not as the first or last character in the name. The
default names are Working and Protecting.
MAC Address
This is a read-only parameter. It displays the address of the Profinet channel
reserved for internal communication.
