Datalogic DX8210 User Manual

Technical Specifications
Reference Manual 279
Technical Specifications
ELECTRICAL FEATURES
Power
Supply Voltage 20-30VDC
Consumption
1 – 0.7 A Max. (note: 1.3A max peak at motor start-up)
20 W typical
Distributable Current
(through I/O connector)
0.6 A Max.
Communication Interfaces
Main RS232
Main RS422 full-duplex
1200 to 115200 bit/s
1200 to 115200 bit/s
Auxiliary RS232 1200 to 115200 bit/s
Ethernet (x2) TCP/IP 100 Mbit/s
EBC Internal Network 100 Mbit/s
Fieldbus
Embedded: EtherNet/IP
Supported through CBX510 connection box or SC5000 models:
PROFINET-IO, PROFIBUS-DP
Inputs
3 opto-coupled and polarity insensitive NPN/PNP digital inputs
(5-30 Vdc)
Outputs 2 opto-coupled software programmable NPN digital outputs
OPTICAL FEATURES
Wavelength 630 to 680 nm
Safety Class Class 2 - EN60825-1; Class II – CDRH
Light Source Visible laser diode
Laser Control Security system to turn laser off in case of motor slow down
Optic Architecture /
Technology
ASTRA™
READING FEATURES
Scan Rate Typ.:1000 scans/s/ Max.
Maximum Resolution Min:0.25mm (10mils)/Max: 1.0mm (40mils)
Max. Reading Distance See section “Reading Diagrams” on page 254
Max. Reading Width See section “Reading Diagrams” on page 254
Max. Depth of Field See section “Reading Diagrams” on page 254
Scan Pattern Type X-Pattern
PHYSICAL FEATURES
Dimensions 381 x 328 x 92.5 mm [15 x 13 x 3.6 in]

Datalogic DX8210 Specifications

General

Brand	Datalogic
Model	DX8210
Category	Barcode Reader
Language	English
