20
DX8210 Barcode Scanner
Chapter 3
Electrical Installation
Preparing for Electrical Installation
Before mounting any components, please do the following:
• Read all instructions before beginning your installation.
• Observe all electrical safety requirements discussed in the Introduction to
this manual.
• Define and confirm the accuracy of your application’s requirements.
• Review all installation-specific drawings.
• Review and plan the power requi
rements for your application.
• Review and plan the communications requirements for your application.
Electrical Installation by Qualified Service Technicians Only! Procedures may involve
exposure to high-voltage. A trained and authorized technician must perform these
procedures. Do not attempt to perform any electrical installation procedures unless
you are a trained technician.
The DX8210 barcode scanners contain electronics that may be affected by electrostatic
discharge (ESD). To prevent personal injury or damage to the unit, please follow the
safety precautions and warnings found in the References section at the beginning of
this manual. Failure to follow these precautions may void your warranty.
The content of this manual may be superseded by any customer-specific documenta-
tion provided by Datalogic. Before proceeding with any installation procedures, be sure
to review ALL documentation, especially content that contains details specific to your
installation.
Everything should be MECHANICALLY INSTALLED before performing any ELECTRICAL
INSTALLATION. See Chapter for mechanical installation details.
Most DX8210
applications are shipped with the CBX connection box and all the neces-
sary cabling required to electrically install the system. If your system requires custom-
length cables or other special wiring, documentation specific to these requirements has
been provided in your shipment. This special documentation supersedes any contradic-
tory content in this manual.
To reduce the possibility of damage to the unit, check all cabling between the scanner
and other devices for accuracy.
