DX8210 Barcode Scanner
Chapter 2
Mechanical Installation
Preparing for Mechanical Installation
Before mounting any components, please do the following:
• Read all instructions before beginning your installation.
• Define and confirm the accuracy of your application’s requirements and
stru
cture position, especially the height of the conveyor from the floor.
• Review all installation-specific drawings provided with your equipment.
• Review and plan the mechanical installation of all devices used in your
a
pplication. Be sure to allow adequate clearance for maintenance.
• Review and plan the power requi
rements for your application.
• Check the contents of the shipping ca
rtons against the packing list.
• Record all product serial numbers.
Electrical Installation by Qualified Service Technicians Only! Procedures may involve
exposure to high-voltage. A trained and authorized technician must perform these
procedures. Do not attempt to perform any electrical installation procedures unless
you are a trained technician.
DX8210 barcode scanners contain electronics that may be affected by electrostatic dis-
charge (ESD). To prevent personal injury or damage to the unit, please follow the safety
precautions and warnings found in the References section at the beginning of this
manual. Failure to follow these precautions may void your warranty.
Application-specific drawings and documents provided by Datalogic supersede any
contradictory content in this manual.
Refer to the Chapter Electrical Installation and Reference Documentation for details on
connecting your barcode scanners to other devices in the system.
