Technical Features
280
DX8210 Barcode Scanner
Weight 7.7 kg (17 lb)
Enclosure Aluminum Alloy
Connections I/O, POWER, ETH1, ETH2; Other connections through CBX510
ENVIRONMENTAL FEATURES
Temperature
Operating: 0 to 50 °C (32 to 122 °F)
Storage: -20 to 70 °C (-4 to 158 °F)
Relative Humidity 10-90% non-condensing
Ambient light immunity >30,000 LUX
Vibration Resistance
SINE vibration as per EN60068-2-6
2-10Hz : 14mm / 13-55Hz : 1.5mm / 70-500Hz : 2g
2h per axis / 3 axes
Shock Resistance
As per EN60068-2-27, 30g / 11ms / 3 times up and 3 times down on
each axis / 3 axes
Protection Class IP65
X-PRESS INTERFACE
LED Indicators Ready, Good, Trigger, Com, Status
Keypad
HMI Keypad for alternative configuration and test mode and Restore
Factory Default
SOFTWARE FEATURES
Readable Code Symbologies
? Code 128
? Interleaved 2 of 5
? Code 39 (Standard)
? GS1-128
? Codabar
? Code 93
? EAN-8/13 - UPC-A/E (including Addon 2 and Addon 5)
Operating Mode On Line, Continuous, PackTrack™, Test
Configuration Methods
e-Genius multilanguage, browser-based, on board HTML web server
interface
X-PRESS™ HMI key functions
Multilabel Reading Up to 10 different symbologies during the same reading phase
Headers and Termina-
tors
Up to 128-byte headers and 128-byte terminators
Code Reconstruction
Technology
ACR™
Parameter Storage Non-volatile internal FLASH
OTHER
Service Options Installation services and on-site training
