User Interface
126
DX8210 Barcode Scanner
Crisplant Protocol Type
Select CSC, CMC, or P10 from the drop-down list. This defines the type of Crisplant
protocol to be used:
CSC: the <CR><LF> characters do not appear at the end of transmitted/
received telegrams
CMC: the <CR><LF> characters appear at the end of transmitted/received
telegrams
P10: the <CR><LF> characters appear at the end of transmitted/received
telegrams
The Parameter Crisplant Manufacturer ID is forced to the Value ‘a’ (61H) and cannot
be modified for this selection, the error messages are modified with respect to CSC
and CMC protocols
Discard Read on Missing Index
Select the check box to enable. When selected, if a Missed Index error occurs, an
empty telegram is sent to the Crisplant Host.
If not selected, and a Missed Index error occurs, the telegram contains the codes
that were read relative to the pack.
