Table 50. ISCSI Device1 Settings screen details
Option Description
Connection 1 Enables or disables the ISCSI connection. This option is set to Disabled by default.
Connection 2 Enables or disables the ISCSI connection. This option is set to Disabled by default.
Connection 1 Settings Enables you to control the configuration for the ISCSI connection.
Connection 2 Settings Enables you to control the configuration for the ISCSI connection.
Connection Order Enables you to control the order for which the ISCSI connections will be
attempted.
Table 51. Connection n Settings screen details
Option Description
Interface NIC interface used for this iSCSI connection.
Protocol This field controls the Internet Protocol used for this iSCSI connection.
VLAN VLAN Enable/Disable for this iSCSI connection.
VLAN ID VLAN ID for this iSCSI connection.
VLAN Priority VLAN priority for this iSCSI connection.
Retry Count Retry Count for this iSCSI connection.
Timeout Timeout for this iSCSI connection in milliseconds.
DHCP DHCP Enable/Disable for this iSCSI connection.
Initiator IP Address Initiator IP Address for this iSCSI connection.
Initiator Subnet Mask Initiator Subnet Mask for this iSCSI connection.
Initiator Gateway Initiator Gateway for this iSCSI connection.
Target info via DHCP Target DHCP Enable/Disable for this iSCSI connection.
Target Name Target name for this iSCSI connection in IQN format.
Target IP Address Target IP Address for this iSCSI connection.
Target Port Target Port for this iSCSI connection. The standard port number for iSCSI
connections is 3260.
Target Boot Lun Target LUN for this iSCSI connection. The value format is a string containing a
hexadecimal-encoded representation of the 64-bit SCSI Logical Unit Number in the
format described in the T10 SCSI Architecture Model specification. This format
consists of four 2-byte fields separated by dashes. In most cases, the human-
oriented logical unit number will be in the high-order two bytes and the low-order
six bytes will be zero. Examples are: 4752-3A4F-6b7e-2F99, 6734-9-156f-127,
4186-9 or 0.
ISID ISID (Initiator Session ID) to use for this iSCSI connection. The value is 6
hexadecimal numbers - such as 3ABBCCDDEEFF or 000000000000. If left blank,
the ISID will be derived from the MAC ID of the assigned NIC interface for the
connection.
Authentication Type Authentication type for this iSCSI connection.
CHAP Type CHAP type for this iSCSI connection.
CHAP Name CHAP name for this iSCSI connection.
CHAP Secret CHAP secret for this iSCSI connection. Minimum length is 12 and maximum is 16.
Reverse CHAP Name Reverse CHAP name for this iSCSI connection.
Reverse CHAP Secret Reverse CHAP secret for this iSCSI connection. Minimum length is 12 and
maximum is 16.
