Chapter 7 Optional AccessoriesMH300

7-52

Fig. 7-38

Unit: mm

The table below is the maximum shielded cable length for drive models with built-in EMC filters. You

Torque: 153.1~204.1 kg-cm /

[132.9~177.2 lb-in.] /

[15.0~20.0 Nm]
