Chapter 7 Optional AccessoriesMH300

7-62

Frame B

NEMA KIT model: MKMH-CBB

Unit: mm [inch]

Fig. 7-64

22.5 [

0.89]

72.0 [2.83]

102.7 [4.04]

76.0 [2.99]

218.0 [8.58]
