Chapter 7 Optional AccessoriesMH300

7-63

Frame C

NEMA KIT model: MKMH-CBC

Unit: mm [inch]

Fig. 7-65

219.0 [8.62]

62.0 [2.44]

87.0 [3.43]

104.2 [4.10]

27.8 [

1.09]

22.5 [

0.89]
