Chapter 11 Summary of Parameter Settings
MH300
Pr. Parameter Name Setting Range Default
020xh: L/h
021xh: m3/s
022xh: m3/h
023xh: GPM
024xh: CFM
xxxxh: Hz
00-26
Maximum user-defined
value
0: Disable
0–65535 (when Pr.00-25 set to no decimal place)
0.0–6553.5 (when Pr.00-25 set to 1 decimal place)
0.00–655.35 (when Pr.00-25 set to 2 decimal places)
0.000–65.535 (when Pr.00-25 set to 3 decimal places)
0
00-27 User-defined value Read only Read only
00-29 LOCAL / REMOTE mode
0: Standard HOA function
1: When switching between local and remote, the drive
stops.
2: When switching between local and remote, the drive
runs with REMOTE settings for frequency and
operation status.
3: When switching between local and remote, the drive
runs with LOCAL settings for frequency and operation
status.
4: When switching between local and remote, the drive
runs with LOCAL settings when switched to Local and
runs with REMOTE settings when switched to Remote
for frequency and operation status.
0
00-30
Master frequency
command source
(HAND, LOCAL)
0: Inputs from digital keypad
1: Inputs from RS-485 communication
2: Inputs from external analog (refer to Pr.03-00)
3: Inputs from external UP / DOWN terminals
(multi-function input terminals)
4: Pulse inputs without direction command
(refer to Pr.10-16 without direction)
5: Pulse inputs with direction command (refer to Pr.10-16)
6: CANopen communication card
8: Communication card (CANopen card not included)
9: PID function
NOTE:
HOA (Hand-Off-Auto) function is valid only when you use with
MO function setting 41 and 56 or with KPC-CC01 (optional).
0
