Pr. Parameter Name Setting Range Default

03-15 AVI analog input filter time 0.00–20.00 sec. 0.01

03-16
ACI analog input filter time 0.00–20.00 sec. 0.01

03-18
Analog input addition
function
0: Disable (AVI, ACI)
1: Enable (analog extension card not included)
0
03-19
Signal loss selection for
analog input 4–20 mA
0: Disable
1: Continue operation at the last frequency
2: Decelerate to 0 Hz
3: Stop immediately and display “ACE”
0

03-20
AFM multi-function output
0: Output frequency (Hz)
1: Frequency command (Hz)
2: Motor speed (Hz)
3: Output current (rms)
4: Output voltage
5: DC bus voltage
6: Power factor
7: Power
8: Output torque
9: AVI
10: ACI
12: Iq current command
13: Iq feedback value
14: Id current command
15: Id feedback value
16: Vq-axis voltage command
17: Vd-axis voltage command
18: Torque command
19: PG2 frequency command
20: CANopen analog output
21: RS-485 analog output
22: Communication card analog output
23: Constant voltage output
0

03-21 AFM analog output gain 0.0–500.0% 100.0

03-22
AFM analog output in REV
direction
0: Absolute value of output voltage
1: Reverse output 0 V; forward output 0
–10 V
2: Reverse output 5
–0 V; forward output 5–10 V
0

03-27 AFM output bias
-100.00
–100.00%
0.00

03-28
AVI terminal input
selection
0: 0–10 V
3: -10–10 V (Pr.03-69–03-74 are valid)
0
