Delta MH300 Series - Page 282

Chapter 11 Summary of Parameter Settings
MH300
11-23
Pr. Parameter Name Setting Range Default

03-29
ACI terminal input
selection
0: 4–20 mA
1: 0–10 V
2: 0–20 mA
0
03-30
PLC analog output
terminal status
Monitor the status of PLC analog output terminals
bit 1: AFM
bit 2: AO10
bit 3: AO11
Read only

03-31 AFM output selection
0: 0–10 V output
1: 0–20 mA output
2: 4–20 mA output
0

03-32
AFM DC output setting
level
0.00–100.00% 0.00

03-35 AFM output filter time 0.00–20.00 sec. 0.01

03-39 VR input selection
0: Disable
1: Frequency command
1

03-44
Multi-function MO output
by AI level source
0: AVI
1: ACI
3: Extension card input terminal AI10
4: Extension card input terminal AI11
0

03-45 AI upper level 1
-100.00
–100.00%
50.00

03-46 AI lower level 2
-100.00
–100.00%
10.00

03-50
Analog input curve
selection
0: Normal curve
1: Three-point curve of AVI (& AI10)
2: Three-point curve of ACI (& AI11)
3: Three-point curve of AVI & ACI (& AI10 & AI11)
(AI10, AI11 are valid when extension card is installed)
0

03-57 ACI lowest point
Pr.03-29 = 1, 0.00–10.00 V
Pr.03-29 ≠ 1, 0.00–20.00 mA
4.00

03-58
ACI proportional lowest
point
0.00–100.00% 0.00

03-59 ACI mid-point
Pr.03-29 = 1, 0.00–10.00 V
Pr.03-29 ≠ 1, 0.00–20.00 mA
12.00

03-60 ACI proportional mid-point 0.00–100.00% 50.00

03-61 ACI highest point
Pr.03-29 = 1, 0.00–10.00 V
Pr.03-29 ≠ 1, 0.00–20.00 mA
20.00

03-62
ACI proportional highest
point
0.00–100.00% 100.00

03-63 AVI voltage lowest point 0.00–10.00 V 0.00

03-64
AVI voltage proportional
lowest point
-100.00–100.00% 0.00
