Chapter 11 Summary of Parameter Settings
MH300
11-33
Pr. Parameter Name Setting Range Default
77: STO Loss 2 (STL2)
78: STO Loss 3 (STL3)
79: U-phase Over-current before run (Aoc)
80: V-phase Over-current before run (boc)
81: W-phase Over-current before run (coc)
82: U-phase output phase loss (oPL1)
83: V-phase output phase loss (oPL2)
84: W-phase output phase loss (oPL3)
87: Low frequency overload protection (oL3)
89: Rotor position detection error (roPd)
101: CANopen guarding error (CGdE)
102: CANopen heartbeat error (CHbE)
104: CANopen bus off error (CbFE)
105: CANopen
index error (CidE)
106: CANopen slave
station setting error (CAdE)
107: CANopen
memory error (CFrE)
111: InrCOM time-out error (InerCOM)
121: Internal communication error (CP20)
123: Internal communication error (CP22)
124: Internal communication error (CP30)
126: Internal communication error (CP32)
127: Firmware version error (CP33)
128: Over-torque 3 (ot3)
129: Over-torque 4 (ot4)
134: Electronics thermal relay 3 protection (EoL3)
135: Electronics thermal relay 4 protection (EoL4)
140: oc hardware error (Hd6)
141: GFF occurs before run (b4GFF)
142: Auto-tuning error 1 (DC test stage) (AUE1)
143: Auto-tuning error 2 (High frequency test stage)
(AUE2)
144: Auto-tuning error 3 (Rotary test stage) (AUE3)

06-23 Fault output option 1 0–65535 (refer to bit table for fault code) 0

06-24 Fault output option 2 0–65535 (refer to bit table for fault code) 0

06-25 Fault output option 3 0–65535 (refer to bit table for fault code) 0

06-26 Fault output option 4 0–65535 (refer to bit table for fault code) 0

06-27
Electronic thermal relay
selection (motor 2)
0: Inverter motor (with external forced cooling)
1: Standard motor (motor with fan on shaft)
2: Disable
2

06-28
Electronic thermal relay
action time (motor 2)
30.0–600.0 sec. 60.0
