Chapter 12 Description of Parameter Settings
MH300
12.1-06-2
 Related parameters:
 Pr.01-13, Pr.01-15, Pr.01-17, Pr.01-19 Deceleration Time 1–4
 Pr.02-13 Multi-function Output 1 (Relay 1)
 Pr.02-16–Pr.02-17 Multi-function Output 2–3 (MO1, 2)
 Pr.06-02 Selection for Over-voltage Stall Prevention

06-02
Selection for Over-voltage Stall Prevention
Default: 0
Settings
0: Traditional over-voltage stall prevention
1: Smart over-voltage stall prevention
2: Traditional over-voltage and smart over-current stall prevention
3: Smart over-voltage and smart over-current stall prevention
 A comparison between traditional stall prevention and smart stall prevention:
Type
Over-voltage
Over-current
Description
Action
Parameter
Description
Action
Parameter
Traditional
Frequency
maintains during
deceleration
Deceleration
stops
Pr.06-01
Frequency
maintains during
acceleration
Acceleration
stops
Pr.06-03
Frequency
decreases at
constant speed
Frequency
gradually
decreases
Pr.06-04
Smart
Frequency
increases during
acceleration /
deceleration /
constant speed
Frequency
gradually
increases
Pr.06-01
Frequency
decreases
during
acceleration /
deceleration
Frequency
gradually
decreases
Pr.06-03
Frequency
decreases at
constant speed
Frequency
gradually
decreases
Pr.06-04
 Pr.06-02 (Selection for stall prevention) can be used with Pr.01-49 (Regenerative energy
restriction control method), but Pr.06-02 cannot work with Pr.01-44 (Auto-acceleration and auto-
deceleration setting).
 When Pr.06-02 or Pr.01-49 is enabled (setting value > 0), Pr.01-44 (Auto-acceleration and auto-
deceleration setting) automatically disables (setting value = 0) and cannot be set; when Pr.01-44
is enabled (setting value > 0), Pr.06-02 and Pr.01-49 automatically disable and cannot be set.
 If you use smart over-voltage or smart over-current stall prevention for industries that require fast
response, you can decrease the deceleration time when needed.
 When using smart over-voltage stall prevention, the drive decelerates to stop with the fastest
deceleration time according to different working condition, rather than the first to fourth
deceleration time (Pr. Pr.01-13, Pr.01-15, Pr.01-17, Pr.01-19).
 For 220V / 440V 160 kW models and above, the default for Pr.06-02 is automatically set to 1
(Smart over-voltage and traditional over-current stall prevention). If you need to set the
deceleration time with Pr. Pr.01-13, Pr.01-15, Pr.01-17, Pr.01-19, set Pr.06-02 = 0.
 Related parameters:
Pr.01-12–01-19 Acceleration / Deceleration time 1–4
Pr.02-13 Multi-function output (Relay 1)
