Delta MH300 Series

Chapter 12 Description of Parameter Settings
MH300
12.1-12-10
12-22
Pulses Per Meter
Default: 0.0
Settings 0.0–6000.0 pulse/m
 When Pr.12-06 = 1, you have to set this parameter.
 If the command source of the linear speed input is the pulses input from PG card or the pulses
input by terminal MI6 / MI7 (Pr.12-19 =3 or 5), then you have to set this parameter.

12-23
Current Linear Speed
Default: 0.0
Settings 0.0–3000.0 m/min
 The linear speed of closed-loop linear speed and speed mode refer to Pr.12-06.
 The range to display in this parameter is based on Pr.12-20 and Pr.12-21.
 When Pr.12-19 is 1, 3, 4, or 5, the current linear speed saved in Pr.12-23 by analog or pulse
command, and this parameter is read only.
 Only when Pr.12-19 is 2, the setting value of the current linear speed can be changed by using
communication.

12-24
Linear Speed Low Pass Filter Time
Default: 0.10
Settings 0.00–100.00 sec.
 This parameter is valid when the command source of the linear speed input is the pulses input
from PG card or the pulses input by terminal MI6 / MI7 (Pr.12-19 =3 or 5).
 Adjust this parameter to restrain the vibration of linear speed.

12-25
Linear Speed Command Acceleration Time
Default: 0.00
Settings 0.00–655.35 sec.
 This parameter is valid when closed-loop linear speed and speed mode (Pr.12-00 = 2).

12-26
Linear Speed Command Deceleration Time
Default: 0.00
Settings 0.00–655.35 sec.
 This parameter is valid when closed-loop linear speed and speed mode (Pr.12-00 = 2).
12-27
Reel Diameter Source
Default: 0
Settings
0: Calculated via linear speed
1: Calculated via analog input selection
2: Calculated via thickness integral, the encoder installed at reel side inputs
by PG card
3: Calculated via thickness integral,
the encoder installed at motor side inputs
by PG card
4: Calculated via
thickness integral, the encoder installed at reel side inputs
by MI6 / MI7 terminals
5: Calculated via thickness integral, the encoder installed at motor side
inputs by MI6 / MI7 terminals
