Chapter 14 Fault CodesMH300
14-66
ID No. Display Fault Name Description
65
Hardware error of
PG card (PGF5)
Hardware error of PG card
Action and Reset
Action condition
1.
The PG card (PG01U/PG02U) can only be used with the permanent
magnetic motor. When the power is ON and Pr. 00-
04=29 pole section
shows 0 or 7 (wiring error or no U/V/W signal input), the PGF5 error
will be activated.
2.
The drive receives the operation command right after the power is ON,
meanwhile, the PG card is not ready yet.
Action time Act immediately
Fault treatment parameter N/A
Reset method Manual reset
Reset condition Reset after cycle the power.
Record Yes
Cause Corrective Actions
Wiring error or there is no
U/V/W
signal input
Re-connect the cables correctly
Encoder failure Verify if it is the UVW encoder
The setting of encoder
parameter
is incorrect
Choose the correct setting of Pr. 10-00
If the motor selection switch of
PG card on the correct position
Check if it is the UVW encoder or Delta encoder
PG card selection is incorrect Install the correct PG card
