Chapter 7 Optional AccessoriesMH300
7-17
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input /
Output
Reactor
(mH)
AC Input Reactor AC Output Reactor
DC
Reactor
(mH)
DC Reactor
Delta Part #
Delta Part #
Weight
(kg)
Delta Part #
Weight
(kg)
VFD5A7MH43ANSAA
VFD5A7MH43ENSAA
VFD5A7MH43AFSAA
6.5 9.75 2.7 DR009A0270 3.5 DR009L0270 3.6 9.355 DR006D0935
VFD9A0MH43ANSAA
VFD9A0MH43ENSAA
VFD9A0MH43AFSAA
10.5 15.75 2.315 DR010A0231 4.5 DR010L0231 5.5 5.345 DR010D0534
VFD13AMH43ANSAA
VFD13AMH43ENSAA
VFD13AMH43AFSAA
15.7 23.55 1.174 DR018A0117 5.3 DR018L0117 6.4 3.119 DR018D0311
VFD17AMH43ANSAA
VFD17AMH43ENSAA
VFD17AMH43AFSAA
20.5 30.75 0.881 DR024AP881 5.8
DR024LP88
1
7.2 3.119 DR018D0311
VFD25AMH43ANSAA
VFD25AMH43ENSAA
VFD25AMH43AFSAA
28 42 0.66 DR032AP660 9
DR032LP660
11 2.338 DR024D0233
VFD32AMH43ANSAA
VFD32AMH43ENSAA
VFD32AMH43AFSAA
36 54 0.639 DR038AP639 9.5
DR038LP639
12 1.754 DR032D0175
VFD38AMH43ANSAA
VFD38AMH43ENSAA
VFD38AMH43AFSAA
41.5 62.25 0.541 DR045AP541 10.5
DR045LP541
16 1.477 DR038D0147
VFD45AMH43ANSAA
VFD45AMH43ENSAA
VFD45AMH43AFSAA
49 73.5 0.405 DR060AP405 11.5
DR060LP405
18 1.247 DR045D0124
VFD60AMH43ANSAA
VFD60AMH43AFSAA
69 103.5 0.334 DR073AP334 25
DR073LP334
25 0.935 DR060DP935
VFD75AMH43ANSAA
VFD75AMH43AFSAA
85 127.5 0.267 DR091AP267 25
DR091LP267
25 N/A N/A
VFD91AMH43ANSAA
VFD91AMH43AFSAA
108 162 0.221 DR110AP221 28
DR110LP221
28 N/A N/A
VFD112MH43ANSAA
VFD112MH43AFSAA
128 192 0.162 DR150AP162 35
DR150LP162
35 N/A N/A
VFD150MH43ANSAA
VFD150MH43AFSAA
180 270 0.135 DR180AP135 42
DR180LP135
42 N/A N/A
Table 7-22
460V, 50–60 Hz / Three-phase - Heavy duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input /
Output
Reactor
(mH)
AC Input Reactor AC Output Reactor
DC
Reactor
(mH)
DC Reactor
Delta Part #
Delta Part #
Weight
(kg)
Delta Part #
Weight
(kg)
VFD1A5MH43ANSAA
VFD1A5MH43ENSAA
VFD1A5MH43AFSAA
1.5 3 8.102 DR003A0810 1.5 DR003L0810 1.5 18.709 DR003D1870
VFD3A0MH43ANSAA
VFD3A0MH43ENSAA
VFD3A0MH43AFSAA
VFD3A0MH43ANSNA
VFD3A0MH43ENSNA
2.7 5.4 8.102 DR003A0810 1.5 DR003L0810 1.5 18.709 DR003D1870
VFD4A2MH43ANSAA
VFD4A2MH43ENSAA
VFD4A2MH43AFSAA
4.2 8.4 6.077 DR004A0607 1.8 DR004L0607 2.5 14.031 DR004D1403
VFD5A7MH43ANSAA
VFD5A7MH43ENSAA
VFD5A7MH43AFSAA
5.5 11 4.05 DR006A0405 2.8 DR006L0405 3.0 9.355 DR006D0935
VFD9A0MH43ANSAA
VFD9A0MH43ENSAA
VFD9A0MH43AFSAA
9 18 2.7 DR009A0270 3.5 DR009L0270 3.6 6.236 DR009D0623
VFD13AMH43ANSAA
VFD13AMH43ENSAA
VFD13AMH43AFSAA
13 26 1.174 DR018A0117 5.3 DR018L0117 6.4 4.677 DR012D0467
VFD17AMH43ANSAA
VFD17AMH43ENSAA
VFD17AMH43AFSAA
17 34 1.174 DR018A0117 5.3 DR018L0117 6.4 3.119 DR018D0311
