Chapter 7 Optional AccessoriesMH300
7-16
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input /
Output
Reactor
(mH)
AC Input Reactor
AC Output Reactor
DC
Reactor
(mH)
DC Reactor
Delta Part #
Delta Part #
Weight
(kg)
Delta Part #
Weight
(kg)
VFD75AMH23ANSAA
VFD75AMH23AFSAA
81 121.5 0.141 DR090AP141 11.5 DR090LP141 15 0.325
DR090DP325
VFD90AMH23ANSAA
VFD90AMH23AFSAA
102 153 0.106 DR105AP106 11.8 DR105LP106 11.8 N/A N/A
VFD120MH23ANSAA
VFD120MH23AFSAA
134 201 0.087 DR146AP087 22 DR146LP087 22 N/A N/A
VFD146MH23ANSAA
VFD146MH23AFSAA
160 240 0.070 DR180AP070 26 DR180LP070 26 N/A N/A
Table 7-20
230V, 50–60 Hz / Three-phase - Heavy duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input /
Output
Reactor
(mH)
AC Input Reactor
AC Output Reactor
DC
Reactor
(mH)
DC Reactor
Delta Part #
Delta Part #
Weight
(kg)
Delta Part #
Weight
(kg)
VFD1A6MH23ANSAA
VFD1A6MH23ENSAA
1.6 3.2 2.536 DR005A0254 1.2 DR005L0254 1.5 5.857 DR005D0585
VFD2A8MH23ANSAA
VFD2A8MH23ENSAA
2.8 5.6 2.536 DR005A0254 1.2 DR005L0254 1.5 5.857 DR005D0585
VFD5A0MH23ANSAA
VFD5A0MH23ENSAA
VFD5A0MH23ANSNA
VFD5A0MH23ENSNA
4.8 9.6 2.536 DR005A0254 1.2 DR005L0254 1.5 5.857 DR005D0585
VFD7A5MH23ANSAA
VFD7A5MH23ENSAA
7.5 15 1.585 DR008A0159 1.7 DR008L0159 2.5 3.66 DR008D0366
VFD11AMH23ANSAA
VFD11AMH23ENSAA
11 22 1.152 DR011A0115 2.5 DR011L0115 3.0 2.662 DR011D0266
VFD17AMH23ANSAA
VFD17AMH23ENSAA
17 34 0.746 DR017AP746 3.2 DR017LP746 3.6 1.722 DR017D0172
VFD25AMH23ANSAA
VFD25AMH23ENSAA
25 50 0.507 DR025AP507 3.8 DR025LP507 5.5 1.172 DR025D0117
VFD33AMH23ANSAA
VFD33AMH23ENSAA
33 66 0.32 DR033AP320 4.5 DR033LP320 6.5 0.851 DR033DP851
VFD49AMH23ANSAA
VFD49AMH23ENSAA
46 92 0.216 DR049AP215 6.5 DR049LP215 8.6 0.574 DR049DP574
VFD65AMH23ANSAA
VFD65AMH23ENSAA
65 130 0.163 DR065AP162 8.5 DR065LP162 12 0.432 DR065DP432
VFD75AMH23ANSAA
VFD75AMH23AFSAA
75 140 0.141 DR090AP141 11.5 DR090LP141 15 0.325 DR090DP325
VFD90AMH23ANSAA
VFD90AMH23AFSAA
90 180 0.106 DR105AP106 11.8 DR105LP106 11.8 N/A N/A
VFD120MH23ANSAA
VFD120MH23AFSAA
120 240 0.087 DR146AP087 22 DR146LP087 22 N/A N/A
VFD146MH23ANSAA
VFD146MH23AFSAA
146 292 0.070 DR180AP070 26 DR180LP070 26 N/A N/A
Table 7-21
460V, 50–60 Hz / Three-phase - Normal duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input /
Output
Reactor
(mH)
AC Input Reactor AC Output Reactor
DC
Reactor
(mH)
DC Reactor
Delta Part #
Delta Part #
Weight
(kg)
Delta Part #
Weight
(kg)
VFD1A5MH43ANSAA
VFD1A5MH43ENSAA
VFD1A5MH43AFSAA
1.8 2.7 8.102 DR003A0810 1.5 DR003L0810 1.5 18.709 DR003D1870
VFD3A0MH43ANSAA
VFD3A0MH43ENSAA
VFD3A0MH43AFSAA
VFD3A0MH43ANSNA
VFD3A0MH43ENSNA
3 4.5 6.077 DR004A0607 1.8 DR004L0607 2.5 18.709 DR003D1870
VFD4A2MH43ANSAA
VFD4A2MH43ENSAA
VFD4A2MH43AFSAA
4.6 6.9 4.05 DR006A0405 2.8 DR006L0405 3.0 14.031 DR004D1403
