Chapter 7 Optional AccessoriesMH300
7-15
230V, 50–60 Hz / Single-phase - Normal duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input / DC
Reactor
(mH)
AC Input / DC Reactor
Output
Reactor
(mH)
AC Output Reactor
Delta Part # Weight (kg) Delta Part # Weight (kg)
VFD1A6MH21ANSAA
VFD1A6MH21ENSAA
VFD1A6MH21AFSAA
1.8 2.7 5.857 DR005D0585 0.8 2.54 DR005L0254 1.5
VFD2A8MH21ANSAA
VFD2A8MH21ENSAA
VFD2A8MH21AFSAA
3.2 4.8 3.66 DR008D0366 0.8 2.54 DR005L0254 1.5
VFD5A0MH21ANSAA
VFD5A0MH21ENSAA
VFD5A0MH21AFSAA
5 7.5 2.66 DR011D0266 1.2 2.54 DR005L0254 1.5
VFD7A5MH21ANSAA
VFD7A5MH21ENSAA
VFD7A5MH21AFSAA
8.5 12.75 1.72 DR017D0172 1.9 1.15 DR011L0115 3.0
VFD11AMH21ANSAA
VFD11AMH21ENSAA
VFD11AMH21AFSAA
12.5 18.75 1.17 DR025D0117 2.8 0.746 DR017LP746 3.6
Table 7-18
230V, 50–60 Hz / Single-phase - Heavy duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input / DC
Reactor
(mH)
AC Input / DC Reactor
Output
Reactor
(mH)
AC Output Reactor
Delta Part # Weight (kg) Delta Part # Weight (kg)
VFD1A6MH21ANSAA
VFD1A6MH21ENSAA
VFD1A6MH21AFSAA
1.6 3.2 5.857 DR005D0585 0.8 2.54 DR005L0254 1.5
VFD2A8MH21ANSAA
VFD2A8MH21ENSAA
VFD2A8MH21AFSAA
2.8 5.6 3.66 DR008D0366 0.8 2.54 DR005L0254 1.5
VFD5A0MH21ANSAA
VFD5A0MH21ENSAA
VFD5A0MH21AFSAA
4.8 9.6 2.66 DR011D0266 1.2 2.54 DR005L0254 1.5
VFD7A5MH21ANSAA
VFD7A5MH21ENSAA
VFD7A5MH21AFSAA
7.5 15 1.72 DR017D0172 1.9 1.59 DR008L0159 2.5
VFD11AMH21ANSAA
VFD11AMH21ENSAA
VFD11AMH21AFSAA
11 22 1.17 DR025D0117 2.8 1.15 DR011L0115 3.0
Table 7-19
230V, 50–60 Hz / Three-phase - Normal duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input /
Output
Reactor
(mH)
AC Input Reactor
AC Output Reactor
DC
Reactor
(mH)
DC Reactor
Delta Part #
Delta Part #
Weight
(kg)
Delta Part #
Weight
(kg)
VFD1A6MH23ANSAA
VFD1A6MH23ENSAA
1.8 2.7 2.536 DR005A0254 1.2 DR005L0254 1.5 5.857 DR005D0585
VFD2A8MH23ANSAA
VFD2A8MH23ENSAA
3.2 4.8 2.536 DR005A0254 1.2 DR005L0254 1.5 5.857 DR005D0585
VFD5A0MH23ANSAA
VFD5A0MH23ENSAA
VFD5A0MH23ANSNA
VFD5A0MH23ENSNA
5 7.5 2.536 DR005A0254 1.2 DR005L0254 1.5 5.857 DR005D0585
VFD7A5MH23ANSAA
VFD7A5MH23ENSAA
8 12 1.585 DR008A0159 1.7 DR008L0159 2.5 3.66 DR008D0366
VFD11AMH23ANSAA
VFD11AMH23ENSAA
12.5 18.75 0.746 DR017AP746 3.2 DR017LP746 3.6 2.662 DR011D0266
VFD17AMH23ANSAA
VFD17AMH23ENSAA
19.5 29.25 0.507 DR025AP507 3.8 DR025LP507 5.5 1.722 DR017D0172
VFD25AMH23ANSAA
VFD25AMH23ENSAA
27 40.5 0.32 DR033AP320 4.5 DR033LP320 6.5 1.172 DR025D0117
VFD33AMH23ANSAA
VFD33AMH23ENSAA
36 54 0.216 DR049AP215 6.5 DR049LP215 8.6 0.851
DR033DP851
VFD49AMH23ANSAA
VFD49AMH23ENSAA
51 76.5 0.216 DR049AP215 6.5 DR049LP215 8.6 0.574
DR049DP574
VFD65AMH23ANSAA
VFD65AMH23ENSAA
69 103.5 0.169 DR075AP170 10 DR075LP170 14.5. 0.432
DR065DP432
