Chapter 16 PLC Function ApplicationsMH300
Special D Function Descriptions R/W
D1032 AI11 value (0.00–100.00%) RO
D1033
–
D1034
-- --
D1035 -- --
D1036 Servo error bit RO
D1037 Drive output frequency RO
D1038 DC bus voltage RO
D1039 Output voltage RO
D1040 Analog output value AFM (-100.00–100.00%) RW
D1041 Analog output value AO10 (0.00–100.00%) RW
D1042 Analog output value AO11 (0.00–100.00%) RW
D1043
Can be user-defined (is displayed on panel when Pr.00-04 is set to
method is Cxxx)
RW
D1044 -- -
D1045 -- --
D1046
–
D1049
-- --
D1050
Actual operation mode
0: Speed
2: Torque
RO
D1051 -- --
D1052 -- --
D1053 Actual torque RO
D1054 MI7 current calculated count value (low word) RO
D1055 MI7 current calculated count value (high word) RO
D1056 Rotational speed corresponding to MI7 RO
D1057 MI7’s rotating speed ratio RW
D1058 MI7 refresh rate (ms) corresponding to rotating speed RW
D1059 Number of nibbles of rotating speed corresponding to MI7 (0–3) RW
D1060
Operation mode setting
0: Speed
2: Torque
RW
D1061 485 Modbus communication time-out time (ms) RW
D1062 Torque command (torque limit in speed mode) RW
D1063
–
D1069
-- --
D1100 Target frequency RO
