8.2.15.5 Operation check with anti-tipping device load
CAUTION
It is mandatory to check the proper operation of the anti-tipping device at the beginning of each work
restart.
For a proper check of the device carry out the following
operations(fig.1504381):
– Place the machine on a flat, level surface and engage the
parkingbrake.
– Make sure that the equipment is properly installed on the
machineandthatitissuitableforitscapacity.
– Checkthatthedisplayoftheantitippingdeviceissetforthe
equipmentinstalled.
– Checkthattheoilinthehydraulicsystemisatapprox.50°C
60°C.
– Refertothecapacitydiagramoftheequipmentinstalledand
with closed boom pick up a load approximately weighing
50%ofmaximumcapacity.
– Raisetheloadatabout50cmfromtheground.
– Withtheengineidling,extendtheboomslowly.Duringthis
operation,checkthedisplayoftheantitippingdevice.When
theredzoneisreached,thecontinuous audible signal will
operate and the extension movement will stop
simultaneously.
– At this point, check that aggravating movements for the
equipmentassembledarenotpermitted.
– Checkthatthestoppingoccursatthepointindicatedinthe
capacitydiagramshowninnotebookinsidethecab.
– Intheeventthateverythingisworkingproperly,itispossible
tobeginthework.
150438-1
DANGER
If there are any faults of the safety devices, stop the work until it has been repaired.
Contact the Dieci service center.
