8.2.12 Info
Thesoftwareversions“1”areindicatedontheInfopage.
ToaccesstheInfopage:
– PresstheMENUbutton,
– SelecttheInfoicon,
– PresstheOKbutton,
Press the MENU button at any time to return to the Home
screen.
1
151010-1
8.2.13 Active errors
Thepresenceof errors will be reported by the general warning
icon,bytheacousticsignallasting1.5sec.andbythedisplaying
oftheerrorcodeontheHomescreeninsteadofthetime.
150432-1
Inthepresenceofmorethanoneerror,theerrorcodeswillbedisplayedcyclicallyevery2sec.ontheHome
screen.Attheendofthecycleshowingalltheactiveerrors,aniconwillbedisplayedthatindicatestheuserto
accesstheActiveErrorspagetoviewallactiveerrorsinthattime.
IncaseofanerrorfromtheSAR,theacousticsignalwillbecontinuousandtheerrorcodewillremainfixedon
theHomescreen.PresstheOKbuttontostopthesoundoftheacousticsignalandresumetheactiveerrors
displayingcycle.
ToentertheActiveerrorspageitisnecessaryto:
– PresstheMENUbutton,
– SelecttheActiveerrorsicon,
– PresstheOKbutton,
Use the UP and DOWN buttons to scroll though the pages if
there are several errors. The arrows at the bottom of page "1"
indicate the presence and directions in which the additional
pagesflow.
Press the MENU button at any time to return to the Home
screen.
150432-2
Eacherrorcodeisassociatedwithaniconthatidentifiesthenatureoftheerror:
Icon Example Description
000000000 Parkingbrakeserrorsorbrakesfailure
000 SARerrors
