9.7 Trailers braking *
NOTICE
All the different types of trailer braking are optional accessories.
The warning light"1" (fig. 1502081) indicates a failure or low
pressureinthetrailerbrakesystem.
Thepressuregauge (fig.1502082)on theleftinstrument panel
indicatesthepressureofthetrailerbrakingsystem.
The maximum pressure of the pneumatic system is 0.72 MPa
(104.4psi).
1502081
1502082
DANGER
Do not move the vehicle until the warning light goes off because the trailer might not brake regularly.
Attachthetrailertothetowhitchofthevehicle,andthenmake
theconnectionsofthebrakingsystemofthetrailer.
Adjustthebrakingcontroldistributor(fig.1502083)depending
onthetypeoftrailerandloadtransported. The braking control
distributorisontherearofthevehicle.
– Turn the ring nut to the "+" sign to anticipate the trailer
braking.
– Turntheringnuttothe"-"signtodelaythetrailerbraking.
Therearedifferenttypesoftrailerbraking:
1502083
