Dieci SAMSON AGRI MAX - Engine Maintenance; Belts: Check and Adjustment; Engine Oil: Check and Filling up; Air Filter: Cleaning and Replacement

Maintenance | 12
DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 231
12.9 Engine maintenance
NOTICE
For the engine maintenance operations, refer to it manual.
12.9.1 Belts: Check and adjustment
Checkthatthebelt“1”(fig.1507261)doesnothavecuts,cracks
orrubbingsigns;whenindoubt,installanewbelt.
Makesurethatthebeltisproperlyfitonthepulleysandthatthe
tensionerisworkingproperly.
NOTICE!If the belt does not appear in good condition,
replace it with a new one.
150726-1
12.9.2 Engine oil: Check and filling up
– Check the level with the vehicle on level ground and the
engineturnedoff.Waitatleast5minutestoallowtheoilto
settleintothesump.
– Pullout thedipstick "1"(fig.1507271),cleanitandinsertit
backfullydown.
– Pulloutagainthedipstick"1"andcheckthattheoillevelis
betweenthe"MIN"and"MAX"mark.
– Putbackthedipstickandinsertitfullydown.
– Ifnecessary,addoilfromthecapontheengine“2”.
Fortheamountandtypeofoil,refertotheenginemanual.
150727-1
WARNING
Do not fill beyond the "MAX" mark; if the amount is excessive, oil burns with production
of smoke and possible damage to the DPF.
Never operate the engine with the oil level below the "MIN" mark.
12.10 Air filter: Cleaning and replacement
CAUTION
The inspection, cleaning and replacement must be carried out with the machine in the maintenance
position.
