Dieci SAMSON AGRI MAX - Return Hydraulic Oil Filter; 2 Speed Transmission Maintenance; Oil Change: Inspection; Oil Change: Check and Replacement

Maintenance | 12
DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 237
12.12.3 Return hydraulic oil filter
To replace the hydraulic oil filter (fig. 1507381) carry out the
followingoperations:
– Preparethevehicleinthemaintenanceposition.
– Turnonthevehicleandlifttheboomjustenoughtoinsert
thesafetyrodontheliftingcylinderrod.
– Turnofftheengineandremovetheignitionkey,placeasign
inthecabshowing"Maintenanceinprogress".
– Allowengineandhydraulicoiltocooldown.
– Insertthe"boomsupport"safetyrodontherodofthelifting
cylinder,applyappropriatesafetysupportstothetelescopic
boom.
– Placeacontainerundertheoilfilter"6"tocollecttheoilthat
mayspillduringthechange.
– Replace the filter "6", lightly oil the gasket and tighten by
handfor3/4ofaturn.
150738-1
12.13 2 speed transmission maintenance
12.13.1 Oil change: Inspection
– Setthemachineinthemaintenanceposition.
– Placeacontainerunderthegearbox.
– Take the level cap off “1” (fig. 1506191), oil must leak out
fromthehole.
– Ifnecessary,topupthroughtheholeofthecapuntiltheoil
seepsthrough.
1
2
1506191
12.13.2 Oil change: Check and replacement
– Setthemachineinthemaintenanceposition.
– Placeacontainerunderthegearbox.
– Removethelevelcap“1”(fig.1506201)andthedraincap“2”.
– Allowtheoiltocompletelydrainout.
– Refitthedraincapandtightenitsecurely.
– Topupwithapprovedtypeof oil through the cap"1"until
theoilseepsthrough.
1
2
1506201
