22 Wiring diagram
22.1 Components legend
Name Function Sheet
A134 Condenserfanreversingcontrolunit 12
A151 Carradio 11
A219 A/CCONTROLUNIT 12
A241 Antitippingcontrolunit 7
A265 FLASHERCONTROLUNIT 10
A283 MULTILINK 4
A565 Preheatingcontrolunit 1
B130 SEATMICROSWITCH 3
B138 Inchingmicroswitch 2
B139 Stoplightsmicroswitch 10
B181 Transmissiondisconnectmicroswitch 3
B182 Temperatureprobe 12
B192 BRAKESOILLEVELSENSOR 5
B205 Airconditioningsystempressureswitch 12
B234 BRAKEPEDALPRESSURESWITCH 6
B504 RIGHTFRONTLOWEREDOUTRIGGERMICTROSWITCH 6
B512 Fuellevelswitch 5
B513 Hydraulicoilfilter 5
B534 Engagedgearmicroswitch 3
B535 2ndGEARPRESSURESWITCH 3
B537 Waterthermistor 5
B538 Engineoillowpressurepressureswitch 5
B542 Servobrakeaccumulatorpressureswitch 5
B550 RIGHTFRONTLOWEREDOUTRIGGERMICTROSWITCH 6
B554 NEGATIVEBRAKEPRESSURESWITCH 3
B558 Frontaxlealignmentproximityswitch 6
B559 Axleloadcellsensor 7
B560 Rearaxlealignmentproximityswitch 6
B561 Filterthermistor 1
B585 Speedsensor 5
B602 LEFTFRONTCLOSEDOUTRIGGERMICTROSWITCH 6
B603 RIGHTFRONTOUTRIGGERMICTROSWITCH 6
B643 Closedboommicroswitch 7
B762 Closedboommicroswitch 8
B763 30°boommicroswitch 8
E102 RIGHTFRONTWORKLIGHT 11
E103 RIGHTREARWORKLIGHT 11
E104 LEFTFRONTWORKLIGHT 11
E118 LEFTREARWORKLIGHT 11
