8.22.1.1 Remote control display
1
2
5
4
3
Description
1 LCDdisplay
2 Antitippingledsignaling
3 RemotecontrolstatusLED
4 RemotecontrolbatterystatusLED
5 Notused
W Currentweight
M Maximumweight
R Radius
H Loadheightfromtheground
A Boomangle
L Boomextensionlength
xx* Installedequipmentcode
Forksoperatingmodeicon
Hookoperatingmodeicon
Basketoperatingmodeicon
Batterychargelevel
Remotecontrolsignallevel
Fuellowlevelicon
Generalalarmicon
Activeelectriccontacticon
Solenoidvalveonboomheadicon
F1functionicon(optionaldependingontheequipmentinstalled)
F2functionicon(optionaldependingontheequipmentinstalled)
