Dieci SAMSON AGRI MAX - Continuous Oil Function; Continuous Oil Function on Joystick with Capacitive Deadman

8 | Components description
126 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
8.7 Continuous oil function *
NOTICE
The oil continuous function is an accessory option.
Thecontinuousoilfunctionallowstomaintainaconstantvolumeofoilpassingthroughthehydraulicsockets
withoutactingconsistentlyontheselectorofthejoystick.
DANGER
Do not change the hydraulic couplers selection while using the continuous oil function;
the hydraulic coupler would begin to work directly according to the flow set by the
function.
Risk of damage to things, people and mechanics of the machine or equipment.
CAUTION
With the continuous oil function enabled do not move away from the driver's cab.
NOTICE
With the continuous oil function active it is still possible to use the joystick to move the boom.
8.7.1 Continuous oil function on Joystick with capacitive deadman
To activate the function it is necessary to (fig. 150455-1):
– Select, using the hydraulic couplers switch andthe coupler
switchontheboomhead(ifinstalled),thedesiredhydraulic
coupleronwhichtoactivatethefunction.
– Usetheservicesrolleronthejoysticktosetthedesiredflow
ofoil.
– Maintain the flow of oil through the services roller and
simultaneously press the button "6" to activate the
continuousoilfunction.
Whenlightofbutton6ison,onthejoystick,itindicatesthatthe
continuousoilfunctionisactive.
To disable the function it is necessary to:
– Pressthebutton"6".
Whenthelightofbutton"6"onthejoystickgoesoff,itindicates
thatthecontinuousoilfunctionisdisabled.
1
2
3
4
6
5
150455-1
