8.2.7 Boom chains Error icon
Theicon(fig.1509301)indicateslooseningorbreakingofthetelescopicboomchains.
Whentheiconturnson,stoptheworkingoperationsandservicethechains.
1500930
1
CAUTION
Contact an authorized service center
Consult the Control Log and the Maintenance Log to know the timelines and operations to be carried out.
DANGER
If at least one chain is loose or broken, activate the emergency procedure for the basket recovery.
Incaseofbreakageofoneorbothchains,inadditiontotheindicationonthedisplay:
– Anacousticsignalisactivatedbothinthecabandoutside,whichcanbestoppedbypressingthe"OK"
buttonontheinstrumentpanel.
– Ifthepassengerbasketisused,thegreenlightonthecontrolpanelflashes.
8.2.8 Levelness Icon
Thelevelnessiconindicateswhenthevehicleisinaworkingconditionwithinthemaximumtiltinglimitsset
bythemanufacturer.
A Green The icon indicates that the vehicle is within the working limits and can
operatenormally.
B Red Theiconindicatesthatthevehicleisoutoftheallowedtiltinglimitsandmust
beleveledinordertoproceedwiththework.
Whenworkingwiththepassengerbasket,thepilotlight"B"turnsontogetherwithanacousticsignalthatcan
besilencedbypressingthe"OK"buttonontheinstrumentpanel.
It is possible to see the exact values on the outriggers page, by holding down the "Outriggers consent"
button.
8.2.9 Steering mode icon
TheSteeringmodeiconshowsthesteeringmodecurrentlyselectedandoperating.
Icon Description
Frontsteeringwheels
Foursteeringwheels
Transversesteering
