Dieci SAMSON AGRI MAX - Caisson Descent

Agriculture components description | 9
DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 161
9.3 Caisson descent **
NOTICE
* The Caisson Descent is an optional accessory for the agricultural sector available only on vehicles with
open center distributor.
The Caisson Descent allows to use equipment or trailers with
singleacting cylinders, if connected to the rear YELLOW
hydraulicsocket.
To put the socket under pressure it is necessary to:
– Select the rear GREEN socket with the selector hydraulic
socketselector.
– Usetheservicescontroltoliftthecaisson.
– After reaching the desired height release the control. The
trailerwillremainstationaryinthatposition.
To relieve pressure from the socket it is necessary to:
– Press the Caisson Descent button (fig. 1503091) and hold
downuntilneeded.
1
150309-1
150309-2
DANGER
When using the Caisson Descent, make sure that nobody is in range of the vehicle and if the trailer is
connected to it. Danger of crushing.
CAUTION
When using the Caisson Descent (YELLOW rear hydraulic socket), it is not allowed to use the GREEN rear
hydraulic sockets.
