Dieci SAMSON AGRI MAX - Brakes Maintenance; Brake: Inspection; Brakes Oil: Check and Replacement

12 | Maintenance
238 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
12.14 Brakes maintenance
12.14.1 Brake: Inspection
Visuallycheckthatthejointsofthepedals(fig.1507081)arenot
damagedandthatthepedalstrokeisnotexcessiveortooelastic.
1
DANGER
If irregularities in braking are noticed, contact qualified personnel to verify the cause of
the trouble.
The braking parts also safeguard the operator's safety, it is recommended not to intervene personally on
the braking system trying to eliminate possible anomalies.
12.14.2 Brakes oil: Check and replacement
Whentheindicatorlight”3”(brakefluidlevellow)flashesonthe
central instrument, it means that the brake fluid level has
dropped below the minimum (MIN) and therefore it must be
restored.
Toaccessthetank,removethefrontprotectivecasingofthecab
“1”(fig.1507091)andcheckthattheoillevelisalwaysabovethe
minimumlevel(MIN)indicatedon thetank“2”. Ifnecessarytop
upfromthecap.
WARNING! If the light "3" stays on even after adding
oil, contact a Dieci authorized service center to solve
the problem.
Aslightloweringofthelevelisduetonormalwearofthebrake
discs.
Donotpressthebrakepedaluntilthetoppingupiscompleted.
Makesurethetankisclosedbeforeactingonthepedal.
1
2
3
1507091
