Dieci SAMSON AGRI MAX - Sunshade; Cab Ventilation

Components description | 8
DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 73
8.1.6 Sunshade
TheSunshadeislocatedatthetopofthecab.
TolowertheSunshade,takethehandlelocatedatthecenterof
"1"andloweritdowntolockitthehooksprovided"2".
Toclosethesunshade,lowerthehandle"1"toreleaseitfromthe
hooks"2"andtakebackthesunshadeinclosure.
2
1
8.1.7 Cab ventilation
8.1.7.1 Ventilation adjustment
Toadjusttheventilation,turntheknob“1”.
Clicksindicaterespectively:
0Off
1–Firstspeed
2Secondspeed
3Thirdspeed
1
3
2
8.1.7.2 Air temperature adjustment
To adjust the temperature of the air coming out of the vents,
turntheknob"2":
– Turning the knob clockwise (in the red scale) the
temperatureincreases.
– Turning the knob counterclockwise (in the blue scale) the
temperature decreases until it is next to the outside
temperature.
1
3
2
