Dieci SAMSON AGRI MAX - Remote Control: Description

8 | Components description
152 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
8.22.1 Remote Control: Description
2
11
10
3
1
4
7
8
9
6
5
Fig.1606011
12
13
Fig.1606012
14
15
16
Fig.1606013
1 LCDdisplay 9 Emergencystopbutton
2 Boomup/downlever 10 Vehicleignitionswitch
3 Boomextension/retractionlever 11 Throttlelever
4 Serviceslever 12 Electriccontactonboomheadbutton
5 Turretrotationlever(forrotaryvehicles) 13 Deadmanbutton
6 Up/downswivelinglever 14 Deadmanbutton
7 Movementsspeedlever 15 Remotecontrolon/offkey
8 Boomheadsolenoidvalvelever 16 Remotecontrolandhornenablebutton
Table1: Radiocontroldescription
