8.12 Plate translation unit*
NOTICE
* The plate translation unit is an optional accessory.
The plate translation unit (fig. 1502071) allows the tool holder
plate and related equipment installed, to make small lateral
movements.
To use the Plate translation unit it is necessary to select the
couplersontheboomheadtowhichtheplateTranslationunitis
connected.
Withtheboomheadcoupleractive,usetheservicesrolleronthe
joysticktomovetheplatetotherightorleft.
1502071
WARNING
Before starting to work, make some test movements in an area free of people or things.
