Dieci SAMSON AGRI MAX - Bolts Tightening Torques; Bolts Tightening Torques: Fine Pitch

12 | Maintenance
254 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
12.23 Bolts tightening torques
12.23.1 Bolts tightening torques: Fine pitch
Coefficient of friction
4.8 5.8 6.8 8.8 10.9 12.9
Preload (N)
Tightening
torque:(Nm)
Preload (N)
Tightening
torque:(Nm)
Preload (N)
Tightening
torque:(Nm)
Preload (N)
Tightening
torque:(Nm)
Preload (N)
Tightening
torque:(Nm)
Preload (N)
Tightening
torque:(Nm)
M8
0.10 9798.1 10.87 12247.6 13.59 14697.1 16.31 19596.1 21.75 27557.1 30.58 33068.5 36.70
0.14 9079.5 13.53 11349.4 16.91 13619.3 20.29 18159.1 27.05 25536.2 38.04 30643.4 45.65
M10
0.10 15296.9 21.13 19121.1 26.41 22945.3 31.69 30593.8 42.25 43022.5 59.42 51627.0 71.30
0.14 14175.0 26.27 17718.8 32.84 21262.6 39.41 28350.1 52.55 39867.3 73.89 47840.8 88.67
M10
0.10 16383.6 22.12 20479.5 27.66 24575.4 33.19 32767.2 44.25 46078.8 62.23 55294.6 74.67
0.14 15221.6 27.80 19027.0 34.75 22832.5 41.70 30443.3 55.61 42810.8 78.20 51373.0 93.84
M12
0.10 22020.7 35.83 27525.9 44.79 33031.0 53.75 44041.4 71.67 61933.2 100.78 74319.8 120.94
0.14 20405.8 44.53 25507.2 55.66 30608.7 66.79 40811.6 89.06 57391.3 125.24 68869.5 150.29
M12
0.10 23333.7 37.26 29167.1 46.57 35000.6 55.88 46667.4 74.51 65626.1 104.78 78751.3 125.74
0.14 21669.2 46.70 27086.5 58.38 32503.8 70.06 43338.4 93.41 60944.6 131.36 73133.5 157.63
M14
0.10 31610.0 59.04 39512.5 73.80 47415.0 88.57 63220.0 118.09 88903.1 166.06 106683.
7
199.27
0.14 29345.9 73.92 36682.4 92.40 44018.9 110.89 58691.9 147.85 82535.4 207.91 99042.5 249.49
M16
0.10 42581.3 89.78 53226.6 112.23 63871.9 134.67 85162.5 179.56 119759.
8
252.51 143711.
8
303.02
0.14 39587.8 113.06 49484.7 141.32 59381.6 169.59 79175.5 226.12 111340.
6
317.98 133608.
7
381.57
M18
0.10 51457.2 124.03 64321.5 155.03 77185.8 186.04 102914.
4
248.06 144723.
3
348.83 173668.
0
418.59
0.14 47751.7 155.02 59689.6 193.78 71627.5 232.53 95503.3 310.05 134301.
6
436.00 161161.
9
523.20
M18
0.10 55415.1 130.17 69268.9 162.72 83122.7 195.26 110830.
3
260.35 155855.
1
366.12 187026.
1
439.34
0.14 51577.6 164.67 64472.0 205.84 77366.4 247.01 103155.
2
329.35 145062.
1
463.15 174074.
5
555.77
M20
0.10 65534.1 173.72 81917.7 217.16 98301.2 260.59 131068.
3
347.45 184314.
8
488.60 221177.
8
586.32
0.14 60886.2 218.17 76107.8 272.71 91329.3 327.26 121772.
4
436.34 171242.
5
613.61 205491.
0
736.33
M20
0.10 70114.7 181.58 87643.3 226.97 105172.
0
272.36 140229.
3
363.15 197197.
5
51.68 236637.
0
612.82
0.14 65319.1 230.55 81648.8 288.19 97978.6 345.82 130638.
1
461.10 183709.
9
648.42 220451.
9
778.10
M22
0.10 81220.8 236.88 101526.
0
296.10 121831.
2
355.32 162441.
5
473.76 228433.
4
666.23 274120.
1
799.48
0.14 75533.9 298.75 94417.4 373.43 113300.
9
448.12 151067.
8
597.49 212439.
1
840.22 254927.
0
1008.27
