8 | Components description
156 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
8.22.1.9 Electric contact on boom head button
Thebutton“12”(fig.1606012)allowstoactivatetheelectricalcontactontheboomhead(ifpresent).Press
againthebuttontodisabletheelectricalcontactontheboomhead.
8.22.1.10 Boom head solenoid valve lever
Thelever"8"(fig.1606011)allowstoactivatethesolenoidvalveontheboomhead(ifpresent).
8.22.2 Remote Control: Use
Thevehicle,ifprepared,canbeusedbytheremotecontrol.
Themovementsthatcanbeperformedfromtheremotecontrolare:
– Telescopicboomextension/retraction.
– TelescopicboomUp/Downmovement.
– Swiveling.
– Turretrotation
– Services.
To use the vehicle by remote control carry out the following
operations:
Operations on the vehicle:
Assembletheequipmentonthevehicle,ifnotalreadyinstalled.
(Refertothechapter"Equipmentinstallation"andsetthecorrect
modeofuseofthevehicle)
– Laytheloadontheground.
– Levelthevehicle(ifavailable).
– Placethevehicleonoutriggers.
– Placethegearlevertoneutral"N"position.
– Engagetheparkingbrake.
– Press the switch "1" (fig. 1509121) to enable the controls
from the remote control. Pressing the switch will
automaticallyshutdownthevehicleengine.
– Turnthevehicle ignition key inposition"I"without starting
theengine.
1
150912-1
CAUTION
If the vehicle is designed for the positive/negative jib, connecting any man basket to the vehicle, the
remote control is automatically disabled; therefore only man baskets with pushbutton panel can be used.
Operations on the remote control:
– Turntheremotecontrolon/offknob"15" (fig. 1509122) to
position"I".
– Press the remote control on/off button "16" to enable the
remotecontrol.
– Movethevehicleon/offlever"4"(fig.1509123)upandhold
itfor2seconds.
The ON remote control indicator light will flash green until the
remotecontrolwillremainon.
Whenswitchingontheremotecontrol,itwillemitanalerttone.
14
15
16
