Dieci SAMSON AGRI MAX - Led Work Light; Window Washer Fluid Tank

Maintenance | 12
DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 245
Work light bulb replacement
Toaccessthebulbs(fig.1503051):
– Preparethevehicleinthemaintenanceposition.
– Turnoffthebatterycutoffswitchtodisconnectpowertothe
electricalsystem.
– Removethepowerconnectoratthebackofthelight“1”.
– Presstheconnectorsocketonthelight“2”.
– Turnthesocket,keepingitpressed,toreleaseitfromthelock.
– Perform the same procedure in reverse order to insert the
newbulb.
1
2
150305-1
12.16.4 Led work light*
NOTICE
* The LED work light is an optional accessory.
TheLEDworklight(fig.1503031)doesnotrequiremaintenance.
150303-1
12.17 Window washer fluid tank
Thewasherfluidtankislocatedinthecabontheleftsideofthe
seat“1”(fig.1504661).
Toaddliquidtothetank:
1. Removethefillercap.
2. Addwashingfluidtofillthetank.
3. Putbackthecap.
1
150466-1
CAUTION
During the winter, mix antifreeze fluid to the water.
