Dieci SAMSON AGRI MAX - Fork Block; Fork Extensions

10 | Equipment
198 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
– Depositaloadtotheground.
– Lowerandfullyretracttheboommovingtheforkstoabout1mabovetheground.
– Turnoffthevehicle.
– Getoffthevehicleandmanuallymovetheforkstothedesiredwidth.
10.6.6 Fork block
TheForks lockpreventslateralmovementof theforksoncethe
desiredsettinghasbeenchosen.
Toengagetheforkslock(fig.1505171):
1. Perform the forks installation procedure on the fork carrier
plate.
2. Placetheforkslock"1"intheeyeletoftheforks"2".
3. Inserttheplug"3"completelydowninordertofittheeyelet
"2"andtheforklock"1".
4. Fastentheplugwiththerelatedsafetystops.
5. Aftermovingtheforklaterallytothedesiredposition,fixthe
positionbytighteningthescrew"4".
1
2
3
4
150517-1
10.6.7 Fork extensions
CAUTION
Before starting to use the equipment, inspect and test it as described in the section "Forks
Safe Working Procedures".
Before starting to use the equipment, refer to the "Safety regulations" and "Safe Working Procedures"
described in the manual of the machine on which the equipment is installed.
Theforkextensionsconsistsofthefollowing main components
(fig.1505211):
1. Extension
2. Fastenerpin
3. Safetyplug
1505211
Warnings for use
– Usetheextensionsonlywiththeforksforwhichtheywereconstructed.
– Beforeuse,checktheirintegrity.
– Alwaysapplythepinwiththerelatedsplitpin.
– Donotuseloadsexceedingthoseindicatedbytheforksonwhichtheforkextensionsaremounted.
– Refertothecapacitydiagramoftheforkstowhichareappliedtheextensionforks.
– Makesureoftheloadstability.
