Dieci SAMSON AGRI MAX - Push-Pull Couplings Removal

10 | Equipment
192 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
5. Securethecovertothesocketontheboom“1”(fig.
1505144)throughthesafetylevers(fig.1505144)
6. Checkthattheelectricalcablesarenottrappedinthe
toolholderplateorthattheycanbecrushedbythe
equipmentwhenitwillbeplacedonthefloor.
7. Proceed with the subsequent operations to remove
theequipmentfromthevehicle
2
2
1
150514-2
1505143
2
2
1
1505144
10.5.2 Push-Pull couplings removal
To disconnect the PushPull quick couplings from the
socketontheboomheaditisnecessaryto:
1. Followsteps1,2,3and4oftheproceduretoremove
the equipment from the vehicle described in the
previouschapter
2. Ifaclosedcenterdistributorisinstalledonthevehicle,
carryoutthe proceduresdescribedinthe "Hydraulic
hosesconnections"chaptertoreleasepressureinthe
hydrauliccircuit
3. Turnoffthevehicle
4. Pulltheplugtowardsyourselftoremoveitfromthe
socket(Fig.5I0400)
5. Cleantheplugandsocket,ifsoiled
6. Fit the protective cap on the equipment hydraulic
plugs(Fig.6I0400)
150513-1
