Dieci SAMSON AGRI MAX - Equipment Installation Procedure

10 | Equipment
180 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
10.2 Equipment installation procedure
To properly install equipment carry out the following operations
(fig.1505071):
1. Removethesafetypin"1"(ifinstalled)byremovingthesafety
pins"2"andliftingthelockingpins"3".
2. Placetheequipmentonaflatnotyieldingsurface,tobeableto
smoothlyengageitwiththetoolholderplateofthemachine.
3. Placethemachinewiththeboomloweredparalleltothetool.
Approachthetoolholderplatetotheaccessoryretractingthe
telescopicboom.Themachinecannotextendtheboomifitis
completely lowered. Slightly raise the boom to be able to
extendit.
4. Usingthe tiltingmovement,rotatethetoolholderplate door
downward.Bringthetopoftheplateunderthelockinghooks
ofthetool.
5. Slightlylifttheboomandrotatethetoolholderplateupwards,
thusmakingtheequipmentadheretothetoolholderplateof
themachine.Duringthisoperation,makesurethatnopersonis
inthevicinityoftheequipmentorthemachineboom.
6. Turnofftheengineandgetoutofthemachine.
7. Liftthelockpin“1”andinsertthesafetypins“3”intheirseats
ontoolholderplate,passingthroughthecorrespondingslots
of the equipment. In the case the two holes do not match,
performthestepsdescribedinchapter"Safetypinoutline"
8. Fitthesafetypin“2”onthepinsjustinserted.
9. Intheeventthat the equipment needs electrical or hydraulic
connections, refer to the "Hydraulic hoses connection" and
"Electricalcablesconnection"chapters.
10. Onceproperlyfixedtheequipment,turnonthemachineand
setthecorrectmodeofoperationofthemachinerelatedtothe
newlyinstalledequipment:
11. Consulttheuseandmaintenancemanualofthemachinetoset
thecorrectmodeofuse.
12. Checkthatinthecabthereisthecapacitydiagramrelatedto
themachineandtotheequipmentjustinstalled.
1
3
2
150507-1
1505072
