10 | Equipment
194 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
10.5.3 Flat-Face couplings removal
TodisconnecttheFlatFacequickcouplings:
1. Followsteps1,2,3and4oftheproceduretoremove
the equipment from the vehicle described in the
previouschapter.
2. Ifaclosedcenterdistributorisinstalledonthevehicle,
perform the procedures described in the "Hydraulic
hosesconnections"chaptertoreleasepressureinthe
hydrauliccircuit.
3. Turnoffthevehicle.
4. Turn the socket ring to match the recess with the
position of the ball placed on the socket (fig.
1505161).
5. Pushthesocketring“1”(fig.1505162).
6. Pullofftheplug“2”(fig.1505162)
7. Cleantheplugandsocket,ifsoiled.
8. Carryoutthesameoperationforbothtubes.
9. Checkthatthehydraulichosesarenottrappedinthe
toolholderplateorthattheycanbecrushedbythe
equipmentwhenitwillbeplacedonthefloor.
10. Proceed with the subsequent operations to remove
theequipmentfromthevehicle.
150516-1
1
2
150516-2
10.6 Forks
10.6.1 Identification
Theterm"Fork"meansthepairofforkstobeinstalledonthevehicle.
Thepurposeofthisequipmentistheliftingandhandlingofaloadfromthegroundupwards,andviceversa.
NOTICE
The forks may be provided with a spreader/shifter that allows to position the distance between the forks
more quickly and safely.
The data necessary for the identification of the forks are
positionedontherightsideoftheforks,intheupperpart“A”(fig.
1505181).
Belowaretheidentificationdata(theirordermaybedifferenton
theforks).
Toensureapromptandefficientservicewhenorderingpartsor
when requesting information or technical clarification always
specifytheidentificationdetails.
Therefore we recommend to note the data relating to the
accessoryinyourpossessioninordertosafelyandquicklyidentify
theminthefuture,incaseofneed.
A
2
1
3
150518-1
