10.2.1 Safety pin outline
Some equipment pieces are provided with two 2position
outlinesto givethepossibilitytouse theequipmentonseveral
modelsofmachines.
Theoutlinesarelocatedonbothsidesofthehookstothetool
holderplateofthemachine.
Tochangetheirposition,unscrewtheboltswithspecialkeys(fig.
1505081), rotate the outlines and reassemble tightening the
boltswiththeappropriatetighteningtorque(seethevehicleuse
andmaintenancemanual).
150508-1
DANGER
If the outlines are not present on the accessory, the pins of the tool-holder plate have no
points of engagement with this and consequently the tool could raise and fall at any time,
with danger of load falling, risk of damage to objects and persons, risk of tipping or
sudden loss of stability of the vehicle.
It is mandatory to always work with the outlines in the correct position and tightened to the correct
torque.
