Dieci SAMSON AGRI MAX - Machine Towing with Electrical Panel on; Towing the Machine with Engine in Failure

Emergency procedure | 11
DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 215
11.1.1 Machine towing with electrical panel on
Ifitisnecessarytotowthemachinewiththeelectricalpanelin
operation(forexample,transmissionfailure)followthefollowing
steps:
– Turn the machine off by turning the ignition key “0” (fig.
1505671).
– Attachthetowingbracketbetweentowingvehicleandthe
vehicle in failure at the points prearranged for towing (fig.
1505672).
– Makesurethatthemachineisinastableconfigurationand
lockthewheelswithchockstopreventaccidentalmovement
ofthemachine.
– Removethelowerprotectivecasingbyremovingthescrews
withawrenchsize13.
– Followthestepsdescribedinthechapter"Manuallydisable
thetransmission".
– Switchontheelectricalpanelbyturningtheignitionkeyto
position“1”(fig.1505671).
– Disengagetheparkingbrakeswitch.
– Removethewheelschock.
– Duringtowing,remainseatedinthedriver'sseattoprevent
theparkingbrakefromengagingautomatically.
150567-1
150567-2
11.1.2 Towing the machine with engine in failure
Incaseitisnecessarytotowthemachinewithengineinfailure,
followthefollowingsteps:
– Attachthetowingbracketbetweentowingvehicleandthe
vehicle in failure at the points prearranged for towing (fig.
1505681).
– Makesurethatthemachineisinastableconfigurationand
lockthewheelswithchockstopreventaccidentalmovement
ofthemachine.
– Followthestepsinthesection"Manuallydisabletheparking
brakeonthevehiclefrontaxle".
– Followthestepsdescribedinthechapter"Manuallydisable
thetowing".
150568-1
