11 | Emergency procedure

216 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A

DANGER

With the engine off, the drive and parking brake are still active.

Towing the machine with active drive and brake can cause serious damage to the machine and create

dangerous situations.
