Dieci SAMSON AGRI MAX - Joystick with Capacitive Deadman Switch with FNR Function

Components description | 8
DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 115
CONTROL MOVEMENT
Gripbackwards Boomup
Griptotheleft Upwardswivel
Griptotheright Downwardswivel
Extension/retractionrollerforwards Boomextension
Extension/retraction roller
backwards
Boomretraction
Servicesrollerforwards Oiltothehydraulicsocketselected
(colorblueorsign“+”)
Servicesrollerbackwards Oiltothehydraulicsocketselected
(colorredorsign“-”)
NOTICE
The joystick controls correspond to proportional movements of the vehicle.
8.6.2 Joystick with capacitive deadman switch with FNR function
TheJoystickallowsyoutooperateallthetelescopicboommovements.
Itconsistsof(fig.1504503):
1. Grip
2. Capacitivesensor
3. Deadmanbutton
4. Extension/retractionroller
5. Servicesroller
6. F/Rroller(forward/backward)
7. Nbutton(idle)
8. Continuousoilfunctionbutton**
1
2
3
4
8
6
7
5
150450-3
