8 | Components description
116 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
** Components depending on optional equipment or pre
arrangements.
WARNING
The F/R roller and the N button do not need the deadman enable to operate
To enable the F/R roller (forward / backward) is necessary to maintain the movement of the selector lever
in N.
The controls given by the movement selector lever will have priority over those of the joystick.
CAUTION
The deadman joystick function prevents any accidental movements of the boom.
The Joystick features a "deadman" capacitive sensor: to enable it to function you need to place your hand
on the grip "1" correctly so as to activate the capacitive sensor "2".
If your hand is not resting on the capacitive sensor "2", boom movements are disabled.
WARNING
Before operating the boom, make sure that the area around the vehicle is clear.
Make sure that the loads to be lifted are within the vehicle capacity.
Adjust the seat so you can hold the joystick correctly (fig.
1504504).
Itispossibletousethedeadmanbutton“3”ifthesensor“2”fails
toworkproperly.
Unless you hold the joystick correctly or press the deadman
button,allthejoystickfunctionsaredisabled.
1504504
Themovementsthatarepossibleusingthejoystickare:
CONTROL MOVEMENT
Gripforwards Boomdown
Gripbackwards Boomup
Griptotheleft Upwardswivel
