Components description | 8
DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 117
CONTROL MOVEMENT
Griptotheright Downwardswivel
Extension/retractionrollerforwards Boomextension
Extension/retraction roller
backwards
Boomretraction
Servicesrollerforwards Oiltothehydraulicsocketselected
(colorblueorsign“+”)
Servicesrollerbackwards Oiltothehydraulicsocketselected
(colorredorsign“-”)
F/Rrollerforwards The vehicle runs in forwards gear
(F)
F/Rrollerbackward
Thevehiclerunsinreversegear(R)
Nbuttonpressed TheF/Rfunctionisdeactivatedand
thevehiclereturnstoneutral(N)
NOTICE
The joystick controls correspond to proportional movements of the vehicle.
