8 | Components description
154 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
Description
F3functionicon(optionaldependingontheequipmentinstalled)
F4functionicon(optionaldependingontheequipmentinstalled)
HighparticulateaccumulationintheDPFicon
AdBluelowlevelicon
Chainserroricon(presentifthevehicleisprearrangedwithPLE)
Levelnessicon(presentifthevehicleisprearrangedwithPLE)
Table2: Displaydescriptionandlegend
8.22.1.2 Remote control emergency stop button
The emergency stop button "9" (fig. 1606011) turns off the diesel engine of the vehicle and the remote
control,stoppingallmovementsofthevehicleandoftheequipment.
8.22.1.3 Movements speed lever
Themovementsspeedlever"7"(fig.1606011)allowstosetthevehicleboomspeed.
Movetheleveruptosetthefastmovements(haresymbol)
Movetheleverdowntosettheslowmovements(snailsymbol)
8.22.1.4 Throttle lever
Thethrottlelever“11”(fig.1606011)allowstomaintainconstantdieselenginerevolutionsofthevehicle.
Movetheleverforwardtoincreasetheenginerpmof200rpm.
Movetheleverbackwardtodecreasetheenginerpmof200rpm.
Pressadeadmanbuttonontheremotecontroltoresetthesettingsmadewiththethrottlelever.
Thethrottleleverisnotactivewhenoneofthedeadmanbuttonsispressed.
8.22.1.5 Remote control on/off key
Theon/offkey"15"(fig.1606013)allowstoturnonandturnofftheremotecontrol.Toturnontheremote
control,turntheknobfrompositionOtopositionI.
8.22.1.6 Remote control and horn enable button
Thebutton“16”(fig.1606013)isusedbothtoenabletheremotecontrolcommandsandtooperatethehorn
ofthevehicle.
